RV28P3 Rotary Switch Potentiometer
Category： RV28
Rotary Potentiometer RV28P3 Electrical Characteristics Total Resistance 100Ω-2MΩ Total Resistance Tolerance ±20% Max. Operation Voltage 500VAC Rated Power 1~1.5W Slider Noise ≤47mV Terminal Resistance ≥20Ω Max Mechanical Characteristics Total Rotational Angle 260°±10° Rotational Torque 2-20mN.m Rotational Life 10,000 cycles Shaft Material Metal or Plastic Temperature Range -10℃-85℃ FOB Price: US $0.01 - 99/ Piece Min.Order Quantity: 1000 Pieces for Trimming Pot; 100 Pieces for Wire-wound Pot; and etc. Supply Ability: 100000000 Pieces per Month Production Time: 5-10 workdays for regular orders; 1-5 workdays for samples order. Port: Shenzhen, Shanghai, Ningbo, Guangzhou, Chengdu and etc Payment Terms: Western Union, Visa/Master Card, T/T, Paypal, e-checking and etc Services: ODM, OEM
EnquiryProduct Description
| Rotary Potentiometer RV28P3 | ||
| Electrical Characteristics | Total Resistance | 100Ω-2MΩ |
| Total Resistance Tolerance | ±20% | |
| Max. Operation Voltage | 500VAC | |
| Rated Power | 1~1.5W | |
| Slider Noise | ≤47mV | |
| Terminal Resistance | ≥20Ω Max | |
| Mechanical Characteristics | Total Rotational Angle | 260°±10° |
| Rotational Torque | 2-20mN.m | |
| Rotational Life | 10,000 cycles | |
| Shaft Material | Metal or Plastic | |
| Temperature Range | -10℃-85℃ | |
